MicroSlim Rigid Borescope

Borescope

Pro MicroSlim™ .073″ (1.85 mm)

Hawkeye® Pro MicroSlim Borescopes are just .073 inches in diameter, or .084 inches with a mirror tube. MicroSlim Rigid Borescopes are typically used to inspect diesel fuel-injection nozzles miniature hydraulic components and much more. The MicroSlim Rigid Borescopes focusing allows users to focus in small channels.

Specifications

Model Numbers & Prices

Add Video

Buy Now

MicroSlim Rigid Borescope

Product Tube Length Model# Price
Borescope Kits
3" Pro MicroSlim Kit (80 mm) 3" (80mm) MS03-NVK $2,245 Buy Now
5" Pro MicroSlim Kit (80 mm) 5" (120mm) MS05-NVK $2,445 Buy Now
7" Pro MicroSlim Kit (80 mm) 7" (180mm) MS07-NVK $2,645 Buy Now
Borescope Only
3" Pro MicroSlim Borescope 3" (80mm) MS03 $1,645 Buy Now
5" Pro MicroSlim Borescope 5" (120mm) MS05 $1,845 Buy Now
7" Pro MicroSlim Borescope 7" (180mm) MS07 $2,045 Buy Now
Mirror Tubes
3" Pro MicroSlim Mirror Tube 3" (80mm) MTMS-03 $260 Buy Now
5" Pro MicroSlim Mirror Tube 5" (120mm) MTMS-05 $290 Buy Now
7" Pro MicroSlim Mirror Tube 7" (180mm) MTMS-07 $320 Buy Now

Download Pricing Table

Pro MicroSlim™ .073″ (1.85 mm)

Hawkeye® Pro MicroSlim Borescopes are just .073 inches in diameter, or .084 inches with a mirror tube. Use them to inspect diesel fuel-injection nozzles miniature hydraulic components and much more.

Every Hawkeye® Pro Rigid Borescope is designed with professional users in mind. These top-of-the-line rigid borescopes deliver bright, clear, detailed, high-contrast images.

Hawkeye Pro Rigid Borescopes contain:

  • Our latest endoGRINs® image relay lenses
  • Multicoated objective lens
  • LightConcentrator™ light post
  • Independent focusing ring for convenient video and still photography

A Super bright, portable SuperNOVA™ Light, with rechargeable SuperNOVA Lithium-Ion batteries, and a rugged Hawkeye Carrying Case are included with Kit purchases.



Hawkeye® Pro MicroSlim Specifications

Optics
Field-of-View 42°
Direction-of-View 0°
Relay Optics e2 endoGRINs® Glass Relay Lenses
Magnification Borescopes are not fixed magnification like microscopes. See chart.
Mechanical / Construction
Length 3", 5", 7"
Diameter Scope: .073" (1.85 mm), w/ Mirror Tube: .084 (2.13 mm)
Lightpost LightConcentrato™ ACMI configuration, Diameter 0.300"
Eyecup Standard DIN, 32 mm diameter, with independent focusing ring
Materials
Tube 304 Stainless Steel
All Machined Stainless Steel 303 Stainless Steel
Eyecup and Focusing Ring Aluminum, black anodized
Front Window AR coated optical Glass
Illumination Fiber Optical Glass
Relay Optics e2 endoGRINs® gradient index glass lenses
Environmental
Temperature Range Official - 20° to 120° C
Note 1 Hawkeye Pro Rigid Borescopes can be made to operate up to 300 deg. C on a custom Basis. Contact your sales representative for details.
Note 2 These scope were not designed to operate below 0°. However, several of our customers have successfully used the scopes in liquid Nitrogen at 77 deg. K.
Pressure All Hawkeye borescopes we designed only for use at ambient pressure, however, we have several customers who have successfully used Hawkeye Borescopes at pressures up to 500 PSI and down to 10-6 Torr. As the scopes were not specifically designed for this, the operator does so at his own risk.
Chemical Resistance All Hawkeye Pro Rigid borescopes (tube only, not the eyepiece end) are water tight and are resistant to most hydrocarbons; oils, gasoline, hydraulic fluid, jet fuel, etc. Exposure to Acids and strong Alkali should be avoided as it will attack the optical window.

Download Specifications
