The Nitinol-sheathed Hawkeye® MicroFlex Semi-Rigid Borescopes contain 10,000 fiber imaging bundles, are 6 inches long, and offer 0º and 90º views. The Semi-Rigid Borescopes offer a unique alternative to the traditional rigid borescopes, because they use fiber to transmit the image allowing us to offer them in much smaller diameters.
| Diameter | Length | DOV | FOV | Pixels | Sheath | Model# | Price | |
|---|---|---|---|---|---|---|---|---|
| 0.035" (0.9 mm) | 6" (150 mm) | 0° | 55° | 10,000 | Stainless | HSR 009 0150 55 | $4,295 | Buy Now |
| 0.035" (0.9 mm) | 6" (150 mm) | 90° | 55° | 10,000 | Stainless | HSR 009 0159 55 | $4,995 | Buy Now |
| 0.059" (1.5 mm) | 6" (150 mm) | 90° | 55° | 10,000 | Stainless | HSR 015 159 055 | $5,995 | Buy Now |
The Nitinol-sheathed Hawkeye® MicroFlex Semi-Rigid Borescopes contain 10,000 fiber imaging bundles, are 6 inches long, and offer 0º and 90º views.
| Optics | |
|---|---|
| Direction-of-View | 0º and 90º |
| Field-of-View | 55º FOV |
| Depth-of-Field | 2-5mm, 1mm for the 90º DOV |
| Distal Focus | Fixed focus lens set |
| Mechanical | |
| Tube Diameter | 0.9mm (.035") 1.5mm (.059") |
| Working Length | 150mm (6 inches) |
| Insertion Tube Bend Radius | N/A |
| Articulation | N/A |
| Tube Construction | Nitinol |
| Environmental | |
| Operating Temperature | 0º to 170º F (-18º to 77º C) |
| Watertight Insertion Tube | Up to 1 atm/1 bar (14.7psig); approx. 30ft water depth |
| Note 1 | The handpiece is splash proof only. |
